NEW FREE-V AND FREE FOIL STRAP INSERTS
Additional off-centre strap inserts allow you to customise your stance with 5 different positioning options for each strap - or go strapless. (Straps sold separately)
GORE™ WATERPROOF 2-WAY VENT
The EPS core of a high volume board is affected by extreme temperature changes. To prevent air pressure build-up we’ve installed a two-way GORE™ Protective Vent on the top deck. This allows air to pass in and out of the board, while preventing water from entering. The vent is factory-fitted and does not require any adjustment.
DOUBLE CONCAVE DECK
There is a significant amount of concave in the deck that works to position the rider lower and makes the board more stable to ride. The concave puts all the volume outside on the rails, so the centre of the board is the low point. It creates the best potential for balancing and is the most comfortable and responsive shape to stand on.
COMPACT OUTLINE WITH GENEROUS NOSE VOLUME
The shorter the board, the more effective it is for pumping, the less swing weight, and the more aerodynamic and manoeuvrable it is when riding up on the foil. The reverse shear of the deck and downward curve in the nose allows for greater control over the board, even when fully submerged on water starts. The extra nose volume was added on top so the boards could be cut short without losing stability and allows you to ride a board 6” shorter. The volume in the nose also stops you nose-diving when you’re paddling into a wave and helps keep the water off the concave deck.
HYBRID CARBON TECHNOLOGY
Lighter weight construction for stiffness, manoeuvrability and glide. The stiffer the board, the better it will pump and the more responsive it feels. A light yet durable epoxy composite laminate, with a balanced carbon and e-glass fibre layup is wrapped around an EPS core. High-density closed cell PVC reinforcement around the foil track mount, leash plug and foot strap inserts spreads the load. An ultra-lightweight double bamboo reinforcement layer under the standing area adds greater impact resistance and rigidity.
INTEGRATED PVC STRUCTURAL STRINGER SYSTEM
The DropBox foil mounting tracks are embedded into a high-density closed-cell PVC block. Two high-density PVC stringers are glued to each side of this block, distributing the load lengthwise, and the full system connects the top and bottom laminate skins for maximum support.
DROPBOX ADJUSTABLE FOIL MOUNTING TRACK
Speed-dial your foil setup. Simply drop your foil pre-assembled with screws and t-nuts into the track, slide it backwards, then tighten the screws to fasten. Our unique structurally-integrated DropBox has a longer track for a wider adjustment range, allowing you to precision-tune the foil set up for your rider weight. A measurement guide next to the track aids correct positioning. Industry-standard 90mm track spacing means the DropBox is compatible with most foil systems.
DEEP-V DOUBLE NOSE CONCAVE
The nose spine and double-concave in the underside of the nose, combined with the steep bevelled rails, helps with touchdown recovery. The V-shape in the bottom contour of the board breaks the water surface on touch down, so the board dives in gently and releases quickly, without sticking. The V also helps to funnel air under the board, which helps it to release faster.
